Thhn Wire Electrical Seven Stranded Wire 1.5mm 2.5mm 25 50mm Electric Cables For House Wiring Pvc 450/750v
5.0
Samples:
$0.01/meter | Min. order : 1 meter
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-1000(meters):15(days),>1000(meters):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Model Number:
BV(B)
Brand Name:
WUCAI
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Cross section
0.75mm,1.5mm,2.5mm,4mm,6mm,16mm
Usage
Housing Cabling
MOQ
100 Meters
Voltage
450/750V
Certification
CE/ROHS/CCC/VDE/CCC/ISO9001:2008
Material
Copper+PVC
Color
Customer's Requirement
Rated voltage
450/750V
Conductor Type
Stranded
Insulation
PVC Insulation Cable
Conductor
Copper Core
Product name
Electric Cable Wire Roll
Conductor Material
Copper, 99.95% Copper
Application
building
Type
insulated
Insulation Material
PVC
Place of Origin
Jiangsu, China
ore type | Seven Stranded |
Applications | Building Wire,House wiring |
Conductor | 99.95% copper |
Insulation | PVC |
Certification | CE CCC ISO9001 |
Rated Voltage | 450/750V |
Nominal cross-sectional area of conductor(mm²) | 2.5-240(mm²) |
Note | The special types of fire-retardent,flame-resisting,low-fume and non-halogon as well as acid-alkaliproof for these cables may be supplied upon requests |
conductor cross-sectional area mm2 | Min. nunber of wire of stranded conductor | Mean overall diameter Max mm | Max. D. C. resistance of copper conductor (20℃) Ω/km | Min. insulation resistance (70℃ Ω/km) | ||
Plain | Metal-coated | |||||
0.75 | 7 | 2.9 | 24.5 | 24.8 | 0.013 | |
1.0 | 7 | 3.1 | 18.1 | 18.2 | 0.012 | |
1.5 | 7 | 3.4 | 12.1 | 12.2 | 0.011 | |
2.5 | 19 | 4.1 | 7.41 | 7.56 | 0.011 | |
4 | 19 | 4.8 | 4.61 | 4.70 | 0.009 | |
6 | 19 | 5.3 | 3.08 | 3.11 | 0.0084 | |
10 | 49 | 7.3 | 1.83 | 1.84 | 0.0072 | |
16 | 49 | 8.6 | 1.15 | 1.16 | 0.0062 | |
25 | 98 | 10.2 | 0.727 | 0.734 | 0.0058 | |
35 | 133 | 11.7 | 0.524 | 0.529 | 0.0052 | |
50 | 133 | 13.9 | 0.387 | 0.391 | 0.0051 | |
70 | 189 | 16.0 | 0.268 | 0.270 | 0.0045 | |
95 | 259 | 18.2 | 0.193 | 0.195 | 0.0044 | |
120 | 259 | 20.2 | 0.153 | 0.154 | 0.0040 | |
150 | 336 | 22.5 | 0.124 | 0.126 | 0.0040 | |
185 | 427 | 24.9 | 0.0991 | 0.100 | 0.0040 | |
240 | 469 | 29.3 | ||||
Company Profile
Wuxi Jiangnan Cable Co., Ltd. (hereinafter referred to as “the Company”)a National Key High and New Tech Enterprise specialized in production, sales and research on cables & wires. It is a national customer satisfaction benchmark enterprise, "Top 500 China's Manufacturing Industry", "Top 500 China's Private Enterprises", "Top 500China's Machinery Industry", and "Top 500 China's Energy Groups", "China's Quality Integrity Enterprise". The "Wu Cai" brand was awarded the title of "Top 500 Asian Brands" and "Internationally Famous Brands Focused on Cultivation and Development in Jiangsu Province".
The company covers an area of more than 650,000 square meters, with a construction area of 650,000 square meters, and total assets of more than 8 billion Yuan. There are more than 3400 employees, among them, junior and senior technical and managerial personnel account for more than 30% of the total number of employees.
The company is located in the national wire and cable industry base -- Guanlin Town, Yixing City, Jiangsu Province. It has always adhered to the business philosophy of "integrity and pragmatic, customer first" and is willing to supply more high quality products, perfect service, as always with new and old friends at home and abroad for sincere cooperation, mutual benefit and win-win!
FAQ
1.What's your advantage?
A: Honest business with competitive price and professional service on export process.
2. How I believe you?
A : We consider honest as the life of our company, we can tell you the contact information of our some other clients for you to check our credit. Besides, there is trade assurance from Alibaba, your order and money will be well guaranteed.
3.Can you give warranty of your products?
A: Yes, we extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service.
4.Where are you? Can I visit you?
A: Sure,welcome to you visit our factory at any time.
5.How about the delivery time?
A: Within 7-15 days after we confirm you requirement.
6.what kind of payment does your company support?
A: T/T, 100% L/C at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
