Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable

Shipping:

Ocean freight

Place of Origin:

China

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1000(meters):15(days),>1000(meters):To be negotiated(days)

Model Number:

YJV 0.6/1kv

Brand Name:

JIANGNAN

Inquiry

Write a Review

Model

YJV

Certification

CE TUV

Rated voltage

0.6/1kv

Core

4 Core

Insulation

XLPE

Conductor

Copper

Product name

Low Voltage Armored Underground Power Cable

Jacket

PVC, PVC Jacket

Conductor Material

Copper

Application

Construction, Underground

Type

LOW VOLTAGE, LOW VOLTAGE

Insulation Material

Xlpe

Place of Origin

China

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 8

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 9

Model:	YJV	product name:	Low Voltage Armoured Cable
Rated· Voltage:	0.6/1kV	Conductor:	Copper
Insulation：	XLPE insulation	Jacket:	PVC
Usage:	For laying in doors,in tunnels and direct in ground, not required to bear external mechanical forces .Single core cable in magnetic duct is not permissible

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 10

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 11

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 12

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 13

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 14

Xlpe Low Voltage 4 Core Copper Cable Armored Underground 0.6/1kv Yjv Power Cable 15

XLPE insulated PVC sheathed power cable for Rated Voltage kV 0.6/1kV

Naninal cross-sectional area of conductor mm2	Insulation thickness mm	Approx overall diameter mm			Cable weight ,Max kg/km
Naninal cross-sectional area of conductor mm2	Insulation thickness mm			Sector	Cable weight ,Max kg/km	Circular
4x1.5	0.7	—	11.2	161
4x2.5	0.7	—	12.1	210
4x4	0.7	—	13.3	280
4x6	0.7	—	14.5	370
4X10	0.7	—	17.9	567
4x16	0.7	—	20.3	806
4x25	0.9	—	24.1	1205
4X35	0.9	—	26.9	1599
4x50*	1.0	—	29.6	2148
4x70*	1.1	32.5	35.2	3050
4x95*	1.1	37.0	39.0	4106
4x120*	1.2	40.0	43.6	5113
4x150*	1.4	43.5	47.6	6302
4x185*	1.6	50.5	53.1	7840
4x240*	1.7	56.5	59.6	10156
4X300*	1.8	61.5	66.3	12671
4x400*	2.0	69.0	69.0	—
