Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables

Inquiry

    oops...!

    no product data.

    Go to homepage
    Write a Review
    Rated Temperature
    70'C
    Packing
    100m/Roll
    Standard
    IEC 60227
    Certification
    ROHS/CCC/VDE/CCC/ISO9001:2008
    Rated voltage
    450/750V
    Conductor Type
    Solid, Solid
    Core
    1 Core
    Product name
    wholesale electrical wire roll
    Conductor Material
    Copper, Copper
    Application
    construction, heating housing and building
    Type
    insulated
    Insulation Material
    PVC, PVC
    Place of Origin
    Jiangsu, China
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 8
    Product Name
    Single-core non-sheathed cable with solid conductor for general purposes
    Model
    600227 IEC 01 (BV)
    Standards
    IEC 600227,GB/T5023-2008
    Custom Standard
    IEC,BS,DIN,ICEA
    No. of Cores
    1
    Conductor Type
    Solid
    Applications
    Building Wire,House wiring
    Conductor
    99.95% copper
    Insulation
    PVC
    Certification
    CE CCC ISO9001
    Rated Voltage
    450/750V
    Nominal cross-sectional area of conductor
    1.5~400(mm²)
    single core cable 16mm2 house construction pvc insulation copper conductor electrical wire cables
    1.Reference Standard:
    The product is manufactured according to the standards of GB/T5023-2008 and JB/T8734-2016 or I EC, BS, DIN, and I CEA up on repuest.
    2.Applications:
    The product is suitable for power intallation, fixed wiring or flexible connection for electrical appliances with rated voltage of 450/750V and below.
    3.Operating characteristics :
    •Rated voltage Uo/U： 450/750V、 300/500V and 300/300V.
    •Max. permissible continuous operating temperature of the conductor.
    4. Main advantages:
    Copper core PVC insulated electric cable is a fine and ideal cable with conductor of plain annealed copper wires,solid or
    stranded.These cables are used for general purpose,as building wire for power, lighting and control wire to electrical
    appliances,suitable for use in conduit and for fixed,protected installation. The cable can be of flame ratardance,fire resistance and other property.
    5. Usages:
    a. Use as home appliance wiring cable, building wire
    b. Use as electrical and electronic equipment internal connecting wire
    c. Use as lighting wire
    d. House wiring cable
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 9
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 10
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 11
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 12
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 13
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 14
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 15
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 16
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 17
    Nominal cross-sectional area of conductor mm2
    Class of conductor
    Nominal insulation thickness mm
    Mean overall diameter Max mm
    Approx, weight of cable kg/km
    Max. D. C. resistance of copper conductor (20℃) Ω/km
    Min. insulation resistance (70℃ Ω/km)
    Plain
    Metal-coated
    1.5
    1
    0.7
    3.2
    19
    12.1
    12.2
    0.011
    1.5
    2
    0.7
    3.3
    20
    12.1
    12.2
    0.010
    2.5
    1
    0.8
    3.9
    30
    7.41
    7.56
    0.010
    2.5
    2
    0.8
    4.0
    32
    7.41
    7.56
    0.009
    4
    1
    0.8
    4.4
    45
    4.61
    4.70
    0.0085
    4
    2
    0.8
    4.6
    47
    4.61
    4.70
    0.0077
    6
    1
    0.8
    5.0
    64
    3.08
    3.11
    0.0070
    6
    2
    0.8
    5.2
    66
    3.08
    3.11
    0.0065
    10
    1
    1.0
    6.4
    107
    L83
    1.84
    0.0070
    10
    2
    1.0
    6.7
    113
    1.83
    1.84
    0.0065
    16
    2
    1.0
    7.8
    170
    1.15
    1.16
    0.0050
    25
    2
    1.2
    9.7
    267
    0.727
    0.734
    0.0050
    35
    2
    1.2
    10.9
    361
    0.524
    0.529
    0.0043
    50
    2
    1.4
    12.8
    490
    0.387
    0.391
    0.0043
    70
    2
    1.4
    14.6
    690
    0.268
    0.270
    0.0035
    95
    2
    1.6
    17.1
    936
    0.193
    0.195
    0.0035
    120
    2
    1.6
    18.8
    1190
    0.153
    0.154
    0.0032
    150
    2
    1.8
    20.9
    1464
    0.124
    0.126
    0.0032
    185
    2
    2.0
    23.3
    1835
    0.0991
    0.100
    0.0032
    240
    2
    2.2
    26.6
    2402
    0.0754
    0.0762
    0.0032
    300
    2
    2.4
    29.6
    3005
    0.0601
    0.0607
    0.0030
    400
    2
    2.6
    33.2
    3828
    0.0470
    0.0475
    0.0028
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 18
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 19
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 20
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 21
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 22
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 23
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 24
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 25
    Wuxi Jiangnan Cable Co., Ltd. (hereinafter referred to as “the Company”)a National Key High and New Tech Enterprise specialized in production, sales and research on cables & wires. It is a national customer satisfaction benchmark enterprise, "Top 500 China's Manufacturing Industry", "Top 500 China's Private Enterprises", "Top 500China's Machinery Industry", and "Top 500 China's Energy Groups", "China's Quality Integrity Enterprise". The "Wu Cai" brand was awarded the title of "Top 500 Asian Brands" and "Internationally Famous Brands Focused on Cultivation and Development in Jiangsu Province". The company covers an area of more than 650,000 square meters, with a construction area of 400,000 square meters, and total assets of more than 8 billion Yuan. There are more than 2,200 employees, among them, junior and senior technical and managerial personnel account for more than 30% of the total number of employees. The company is located in the national wire and cable industry base -- Guanlin Town, Yixing City, Jiangsu Province. It has always adhered to the business philosophy of "integrity and pragmatic, customer first" and is willing to supply more high quality products, perfect service, as always with new and old friends at home and abroad for sincere cooperation, mutual benefit and win-win!
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 26
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 27
    Single Core Cable 16mm2 House Construction Pvc Insulation Copper Conductor Electrical Wire Cables 28
    1.What's your advantage? A: Honest business with competitive price and professional service on export process. 2. How I believe you? A : We consider honest as the life of our company, we can tell you the contact information of our some other clients for you to check our credit. Besides, there is trade assurance from Alibaba, your order and money will be well guaranteed. 3.Can you give warranty of your products? A: Yes, we extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service. 4.Where are you? Can I visit you? A: Sure,welcome to you visit our factory at any time. 5.How about the delivery time? A: Within 7-15 days after we confirm you requirement. 6.what kind of payment does your company support? A: T/T, 100% L/C at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
