Rated voltage 150/250V ethylene propylene insulated marine control cable

 Standard

This product implements: IEC 60092-376 standard.

● Conductor

Electrolytic copper, class 5 (flexible), according to IEC 60228.

● Insulation

Cross-linked polyethylene, type HF XLPE 90ºC, Conforms to IEC 60092-353.

● The standard identification of insulation conductors according to HD 308 is the following

1 x  Natural

3 x Brown + Black + Grey

4 x  Brown + Black + Grey + Blue

Other colors available on request.

Insulation core with white insulation printed with black numerical markings

Sheath prints manufacturer's name, model, voltage, specification, length marking, etc.

● Outer sheath

LSHF polyolefin outer sheath type SHF1 according to IEC 60092-360. Black color.

● Armour

Coverage of 100% composed by aluminium-polyester tape and a tinned copper braid.

    oops...!

    no product data.

    Go to homepage

    Cable Category

    Cable name

    Cable model

    Marine control cable

    Ethylene Propylene insulation Neoprene Sheathed Marine Control Cable

    CKEF/DA/SA/NA

    Ethylene Propylene insulation Neoprene Sheathed Copper Wire Braided Armored Marine Control Cable

    CKEFBO/DA/SA/NA

    Ethylene propylene insulation chloroprene inner sheath steel wire braid armored marine control cable

    CKEF90/DA/SA/NA

    Ethylene propylene insulation chloroprene inner sheath copper wire braid armored PVC outer sheath marine control cable

    CKEF82/DA/SA/NA

    Ethylene propylene insulation neoprene inner sheath steel wire braid armored PVC outer sheath marine control cable

    CKEF92/DA/SA/NA

    Ethylene Propylene insulation PVC Sheathed Marine Control Cable

    CKEV/DA/SA/NA

    READ MORE

    Cable Category

    Cable name

    Cable model

    Marine control cable

    Ethylene propylene insulation PVC inner sheath copper wire braided armored marine control cable

    CKEV80/DA/SA/NA

    Ethylene propylene insulation PVC inner sheath blackberry steel wire braided armored marine control cable

    CKEV90/DA/SA/NA

    Ethylene propylene insulation PVC inner sheath copper wire braid armored PVC outer sheath marine control cable

    CKEV82/DA/SA/NA

    Ethylene-Propylene insulation PVC inner sheath steel wire braid armored PVC outer sheath marine control cable

    CKEV92/DA/SA/NA

    Ethylene propylene insulation cross-linked polyolefin sheathed marine control cable

    CKEPJ/SC/NC

    Ethylene propylene insulation cross-linked polyolefin inner sheath copper wire braid armored marine control cable

    CKEPJ80/SC/NC

    Ethylene Propylene insulation Cross-linked Polyolefin Inner Sheath Steel Wire Braided Armor Marine Control Cable

    CKEPJ90/SC/NC

    Ethylene propylene insulation cross-linked polyolefin inner sheath copper wire braid armored cross-linked polyolefin outer sheath marine control cable

    CKEPJ85/SC/NC

    Ethylene propylene insulation cross-linked polyolefin inner sheath steel wire braid armored cross-linked polyolefin outer sheath marine control cable

    CKEPJ95/SCNC

    Ethylene Propylene insulation Polyolefin Sheathed Marine Control Cable

    CKEPF/SC/NC

    Ethylene propylene insulation polyolefin inner sheath copper wire braid armored marine control cable

    CKEPF80/SC/NC

    Ethylene propylene insulation polyolefin inner sheath steel wire braid armored marine control cable

    CKEPF90/SC/NC

    Ethylene propylene insulation polyolefin inner sheath copper wire braid armored polyolefin outer sheath tire control cable

    CKEPF86/SC/NC

    Ethylene propylene insulation polyolefin inner sheath steel wire braid armored polyolefin outer sheath marine control cable

    CKEPF96/SC/NC

    Product description

    Rated voltage 150/250V ethylene propylene insulated marine control cable 4
    Electrical performance
    Cables rated at AC150/250V
    Rated voltage 150/250V ethylene propylene insulated marine control cable 5
    Thermal performance
    Permissible long-term operating temperature of the cable conductor: 90ºC.
    Highest short-circuit temperature of the cable conductor: 250°C (max. 5 seconds)
    Lowest operating temperature of cable conductors: -40°C (fixed and protected installation)
    Lowest installation temperature of cable conductors: -15°C.
    Customized products with different thermal properties
    e2ddfca5ef2681790c29002853bc107
    Fire performance
    The fire resistance of the cable is in accordance with IEC 60332-1-2 or IEC 60332-3-22.
    Fire resistance of cables in accordance with IEC 60331-21.
    Fire non-propagation according to IEC 60332-3-22. LSHF (Low Smoke Halogen Free) according to IEC 60754-1. Low smoke emission according to IEC 61034: light transmittance > 60%.
    Low corrosive gases emission according to IEC 60754-2.
    5211422a88977ff2e396145aab3dd04
    Mechanical properties
    The minimum bending radius of single-core cables is 12 times the outer diameter of the cable.
    The minimum bending radius of a 3-core cable is 9 times the outer diameter of the cable.
    26fea9ce79c0bad09c8401cb4d19aa2
    Installation conditions
    Open Air.
    In Conduit.
    Applications
    Marine use.
    1f8a692b6631e422375d77efa6a295f
    Products application
    This product is suitable for general control devices in the cabin of ships and offshore oil platforms and other water structures.
